Name: Permanent Magnetic Dehydration Tank Country: China Usage: Applicable to separate useful minerals using magnitude of solid particles C lassification : Separator Accessories Parameters: Introduction： Permanent Magnetic Dehydration Tank is a lab mineral processing facility by use of...
Name: Permanent Magnetic Dehydration Tank
Country: China
Usage: Applicable to separate useful minerals using magnitude of solid particles
Classification: Separator Accessories
Parameters:
Model(Top magnetic series ) | CS-12S | CS-16 (CS-16S) | CS-20 | CS-25 | CS-30 | |
Specification | Φ1200 | Φ1600 | Φ2000 | Φ2500 | Φ3000 | |
Tank | Upper mouth diameter | 1200 | 1600 | 2000 | 2500 | 3000 |
Height |
| 1390 | 1600(1650) | 1800 | 2000 | |
Taper(°) |
| 48 | 48(46) | 50 | 56 | |
Precipitation area(㎡) | 1.5 | 2 | 3 | 4.8 | 7 | |
Magnetic induction(mt) | ≥30 | |||||
Overflow particle size(mm) | 1.5-0 | |||||
Processing capability(t/h) | 25-40 | 30-45 | 35-50 | 40-55 | 45-60 | |
Dimension(mm) | 1500*1500*2200 | 2130*2130*2340 | 2600*2340*2840(2500*2500*2500) | 3200*2900*3000 | 3730*3400*3470 | |
Weight(t) | 1.54 | 1.98 | 2.37(2.3) | 2.62 | 3.12 | |
Introduction：
Permanent Magnetic Dehydration Tank is a lab mineral processing facility by use of differences of specific gravity of minerals and weak magnetism and hindered settling action, allowing separation of iron bearing mineral from gangue and desliming and concentration of minerials.
Application:
Permanent Magnetic Dehydration Tank is to separate useful minerals using magnitude of gravity of solid particles. Additional of magnetic system to increase separation effect brings about mutual absorptions of useful light and fine minerals with the action of magnetic force and aggregates large size grains before being separate our from slimes and dropping rapidly together with coarse concentrates by absorption of conical end magnetic fields. Consequently, the objective of separation is achieved and separation process strengthened.
Features:
1.Improve the recovery rate.
2.Large handling capacity.
3.High efficiency.
Our Services:
Pre-sale services: enthusiasm
We provide you with the process plan, process flow design and manufacturer equipment according to your special demand.
Sale services: servant
Send technicians to the job site for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
After-sale services: faithfulness
To establish long term friendship, we will regularly pay return visit to customers.
In addition, we provide one-year warranty to make sure the product runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
More:
As a professional manufacturer and designer of Permanent Magnetic Dehydration Tank for more than 50 years, we can offer various kinds of products with advanced mechanical equipments and experienced technical workers that we can provide this product on top quality and best price. The product will be shipping from China factory directly to your offered address. We are confident to be the best supplier in China.
